Frame and fork
- Frame: Clean S1 20", made from 6061-T6 aluminium alloy, with 1 1/8" head tube, IS disc brake mounts, black with white and red Clean S1 graphics.
- Forks: Clean S1 20", made of steel, for 1 1/8" external headset, IS disc brake mounts, red with black Clean logos.
Wheels
- Front hub: Clean S1, with rotor mounts, 100 mm spacing, anodized black.
- Rear hub: Clean S1, with rotor mounts, 116 mm spacing, anodized black.
- Chain tensioner: Clean snail cams.
- Front rim: Clean 20", 33 mm wide, anodized black with white and red Clean stickers.
- Rear rim: Clean 20", 33 mm wide, anodized black with white and red Clean stickers.
- Spokes: Clean 1.8 mm, made of steel, black.
- Spoke nipples: Clean, red.
- Rim tape: Clean.
- Front inner tube: Clean 20".
- Rear inner tube: Clean 20".
- Front tyre: Clean Koala 20"x2.00".
- Rear tyre: Clean Koala 19"x2.6".
Brakes
- Front brake: Hydraulic Disc Brake.
- Rear brake: Hydraulic Disc Brake.
- Rotors: Clean 160 mm.
Drivetrain
- Cranks: Clean, 155 mm long, JIS, black.
- Bottom bracket: Clean JIS, sealed bearings.
- Freewheel: Clean 18T, 18 teeth.
- Chain: KMC Z1EHX.
- Rear sprocket: Clean 12T, 12 teeth.
- Pedals:Â Plastic pedals (we recommend replacing them for some higher quality pedals).
- Bashplate: Clean mini-bashplate, anodized red.
Steering
- Headset: Clean 1 1/8" external.
- Stem: Clean 145 mm x 25º.
- Grips: Clean foam.
- Handlebar: Clean S1 aluminium, 720 mm long, 35 mm rise.
Geometry
(1) Wheelbase:Â 1010 mm
-----------------------------------------------
(2) Rear End: 350 mm
-----------------------------------------------
(3) Bottom Bracket Height: +40 mm.
-----------------------------------------------
(4) Head Angle: 71°.
-----------------------------------------------
Weight
- 8.98 kg (verified at Trialbikes).
Additional information:
Some pictures may not match the product described, so please read the description carefully.
This bike is partially set up at our workshop, so the customer will only have to set both the front wheel and the headset up.
If you have any doubts, please contact to info@trial-bikes.com.
| FRONT BRAKE | Disc |
| REAR BRAKE | Disc |
