Crewkerz LAB 18" 740mm Disc Bike

Crewkerz LAB 18" Disc Trials Bike

Crewkerz 18” Kids trials bike, specially designed for kids up to 1.20m tall (4-7 years old). Built with reliable parts: high-rise handlebar, freewheel with 30 engagement points… It’s ideal to learn trials having lots of fun!

Frame and fork
- Frame: Crewkerz LAB 18” 740mm, with disc brake mounts.
- Forks: Crewkerz LAB 18”, made of CroMoly, with disc brake mounts.

Wheels
- Front hub: 100mm 28H.
- Rear hub: 116mm 28H, 10mm screw-on axle, 1.37”x24T.
- Chain tensioner: Crewkerz 7075-T6 snail cams.
- Front rim: Crewkerz 18”, 30mm wide, single-wall design, 28H.
- Rear rim: Crewkerz 18”, 32mm special width for bike trials, single-wall design, 28H.
- Spokes: Steel 2mm.
- Spoke nipples: Steel.
- Inner tubes: Crewkerz 18”.
- Tyres: Innova trial 18” x 2.125”.

Brakes
- Brakes: Alhonga disc brakes, 90mm Alu, 2-finger levers.

Drivetrain
- Cranks: Crewkerz square taper crankset, 152mm long, for screw-on freewheel.
- Freewheel: Crewkerz 30.6, 30 engagement points, 6 pawls, 18 teeth.
- Chain: YBN s20 1/2'' x 3/32”.
- Rear sprocket: Crewkerz 14T screw-on.
- Pedals: Plastic pedals, standard 9/16” thread.
- Bottom bracket: Crewkerz JIS, CrMoly, sealed bearings, 124.5mm long

Steering
- Headset: Crewkerz external 1 1/8”.
- Stem: Crewkerz, 75mm x 25º.
- Grips: Crewkerz rubber grips.
- Handlebar: Crewkerz 7075-T6 aluminium, 105mm high-rise, 580mm long

Geometry

(1) Wheelbase: 740 mm
-----------------------------------------------
(2) Rear End: 290 mm
-----------------------------------------------
(3) Bottom Bracket Height: +30 mm.
-----------------------------------------------
(4) Head Angle: 71.5°.
-----------------------------------------------

Colours
- Black or white, with white, red and black Crewkerzs graphics.

Weight
- 9.02Kg

Additional information:
Some pictures may not match the item described, so please read the description carefully.
This bike is partially set up by our workshop, so the customer will only have to set both the front wheel and the headset up.

If you have any doubts, please contact to info@trial-bikes.com.
