Jitsie Race 105Disc 32H Rear Hub Expand

Jitsie Race 105Disc 32H Rear Hub

JITSIE JITSIE

New

 Description and materials

More details

99,17€

Color .

 Black


 Red

Ask a question

 Description and materials
- New Jitsie Race 105Disc ultralight rear disc hub, designed in Belgium and manufactured in Europe, as part of the Jitsie Race range.
- This is a special edition that features a 105mm spacing, specifically designed for using with Monty frames, which require narrower hubs.
- Developed and tested for several months by Multi-World Champion Dani Comas, along with world class riders like Ion Areitio and Rick Koekoek.
- Currently, the world’s lightest rear disc hub for trials!
- Features the exclusive Jitsie design, with the unique hub shell profile that gradually tapers towards the non-drive side of the hub to save unnecessary weight.
- The hub shell is made from high quality 6061 T6 aluminium.
- 105mm spacing, suitable for most Monty frames and those that use this spacing (get in touch if you have any doubts!).
- Please note: this hub is supplied with a 5mm spacer for the non-drive side, which can be replaced by a 2mm one (not supplied) in case you want to run a Jitsie disc protector.
- 10mm 7075 aluminium axle with M6 internal thread.
- Standard 1,37 "x 24 tpi thread allows the use of screw-on freewheels and sprockets.
- International Standard IS 6-bolt disc brake mount.
- Features high quality replaceable sealed bearings, which ensure a smooth running while keeping out all the dirt (mud, water, dust, etc.).
- M6x25 bolts and serrated washers included.
- Only available for rims with 32 holes, for rim brakes.
- Anodized red or black finish, with a silver laser etched JITSIE 105DISC logo.

Dimensions
- 105mm long
- 32 holes

Finishes
- Anodized red or black finish
- Silver laser etched JITSIE 105DISC logo

Weight
- Only 132g!! (+18g of bolts and washers)

Additional information
This hub is only suitable for Monty frames and 32H rims. If you have any doubts, please contact to info@trial-bikes.com

WEIGHT0.132
WEIGHT0.132
WEIGHT0.132
WEIGHT0.132
COLORBlack
COLORRed
SPOKE HOLES32 spokes
BRAKE MOUNTSDisc
